Product characteristics:
| Specification | BRLED-DIN | BRLED-DIN-NG | |
| SPD classification according to EN61643-11 | Type 2 + Type 3 | Type 2 + Type 3 | |
| SPD classification according to IEC61643-11 | Class II + Class III | Class II + Class III | |
| Nominal a.c. voltage | Un | 230V | 230V |
| Max. continuous operating a.c. voltage | Uc | 320V | 320V |
| Norminal discharge current (8/20μs) | In | 5kA | 5kA |
| Maximum discharge current (8/20μs) | Imax | 10kA | 10kA |
| Nominal current | IL | 5A | 5A |
| Combined impluse | Uoc | 10kV | 10kV |
| Voltage protection level | Up | ≤1.5kV | ≤1.5kV |
| Response time | tA | ≤25ns | ≤25ns |
| Operating temperature range | Tu | -40℃-80℃ | -40℃-80℃ |
| Operating state / fault indication | Green light on: OK; Green light off: Replace | ||
| Enclosure materail | Thermoplastic UL94-V0 | ||
| Degree of protection | IP20 | IP20 | |
| Order code | B6017 | B6018 | |
Features:
Surge Protection Device: 320V AC.
Space saving footprint for mounting in confined locations
5kA nominal discharge current (8/20us).
Protection for 230V Systems
Build-in LED status indication.
High performance to size ratio
Degree of protection: IP20.
Fully automatic operation
IEC 61643-11 / EN 61643-11 recognized.
Rated for harsh environments
Features a thermally protected transient over-voltage circuit.
Application:
Protection of LED street light from surge and transient over-voltage caused by the inducted lightning stroke or by internal power systems.
Suitable for harsh environments, and provides high performance circuit protection that saves valuable LED lighting assets, reduces maintenance, prevents unwanted failures and decreases degradation damage for longer lifetimes.
