Product characteristics:
| Specification | BRRJ45L-4L | |
| Test standards | IEC 61643-21 | |
| Nominal voltage | Un | 5V |
| Max. continuous operating d.c. voltage | Uc | 6V |
| Max. continuous operating a.c. voltage | Uc | 4V |
| Nominal current | IL | 0.5A |
| C2 Nominal discharge current (8/20μs) per line | In | 5kA |
| Voltage protection level [line-line] | Up | ≤30V |
| Voltage protection level [line-PG] | Up | ≤500V |
| Response time [line-line] | tA | ≤1ns |
| Response time [line-PG] | tA | ≤100ns |
| Operating temperature range | Tu | -40℃-80℃ |
| Connection input/output | RJ45 socket 4 line | |
| Bandwidth | 30Mbps | |
| Insertion Loss | ≤0.3dB | |
| Enclosure material | aluminium alloy | |
| Degree of protection | IP20 | |
| Order Code | D9030 |
Features:
Insertion loss：≤0.3dB.
Conform to IEC61643-21.
For protecting network devices.
BR-RJ45 SPDs are specially designed to avoid failures in data transfer between equipment inside the same network.
Good discharge capacity, low voltage protection level
It protects the input of the electronic circuits of the network cards against harms due to transient currents.
Quick response, high transmission speed, low signal attenuation
BR-RJ45 is a protector with RJ45 input and output connectors, with a withstanding current up to 5kA for line.
Metallic housing RJ45 connection, easy for installation
Application:
Protect network devices powered from Ethernet such as webcams.
Protect PSE (power-supply equipment) connected to a network from transient overvoltage.
Protect communication devices connected via Ethernet LAN from lightning surge entering through network cables.
Protect a wide array of valuable components such as switch, router, modem, bridge, repeater, or any part of internet service network.
